GERMANY KM PORTABLE STAINLESS STEEL AEROSOL GENERATOR AG250 FOR HEPA FILTER DETECTION TEST

Germany AEROSOL GENERATOR AG250 FOR HEPA DETECTION TEST

Matching with dilutor and particle counter

The AG 250 aerosol generator has been designed for generating test aerosols with defined properties. The in-built flow meter with needle valve allows adjustment of the required concentration. By using the VD 100 dilution system combined with the AG 250 and a particle counter, the control of clean rooms, laminar flow boxes and safety work benches is enabled.

Principal application fields of the AG 250 are filter tests, acceptance- and control measurements of clean rooms, laminar flow boxes and safety work benches. The compact stainless steel housing ensures very easy handling and operation. The AG 250 features a controllable flow meter for adjustment of the required concentration. Centrepiece of the AG 250 is a binary nozzle with pressurized air supply according to the injector principle and a free accessible container for the liquids to be atomized.

Applications

With the AG 250 aerosol generator you are realizing the control of:

• Clean rooms pursuant to VDI 2083/ DIN1946

• Laminar flow boxes

• Cytostatic safety cabinets pursuant to DIN 12980

• Microbiological safety cabinets pursuant to DIN 12950

• Calibration standard: latex aerosols

At a glance

• Volume flow: 0 – 250 l/ h

• Filling qualtity: max. 80 ml

• Power suply: 230 V

• Particles: Di-2-ethylhexyl Sebacate (DEHS), Dioctylphthalate (DOP), Paraffin, Latex, Polyalphaolefins (PAO, Emery 3004) • Gewicht: ca.4,5 Kg

• Maße LxBxH [cm]: 28 x 12 x 16

• Made in Germany by KM
