DI water fogger called smoke generator used for testing clean room QLC series

I'm Online Chat Now

DI water fogger called smoke generator used for testing clean room QLC series

China DI water fogger  called smoke generator used for testing clean room QLC series supplier

Large Image :  DI water fogger called smoke generator used for testing clean room QLC series

Product Details:

Place of Origin: suzhou
Brand Name: Norda
Certification: www.nordachina.com/en
Model Number: QLC series

Payment & Shipping Terms:

Minimum Order Quantity: 1 pc
Price: Best price for you!
Packaging Details: carrying case or carton
Delivery Time: 2-3weeks
Payment Terms: T/T, Western Union
Supply Ability: 200 sets per month
Contact Now
Detailed Product Description
Using: Air Flow Viewer Name: DI Water Fogger
Type: Smoke Generator

 introduction

A breakthrough in the QLC is also the air products (DI water), boot animation, large screen liquid crystal display wind, fog, fog time, automatic memory setting mode, convenient and quick, the fog is about 2 times higher than that of similar products in the United States cleanroomfogger, air quantity can be 15 file adjustment, visual detection effect is more obvious, photo effects more clearly. QLC-III air flow manifold test instrument using ultrasonic atomization principle, DI water mist into a large number of droplets of 0.3-5 microns, the establishment of an aerosol, blown by the fan

Features

1, the lowest cost

2, can be tested more than equal to 100 levels of the clean room of the laminar flow

3, the average grain size from 5 microns, the photographic effect is better, the fog particle suspension is better

4, according to the different environment can choose the most suitable for the spray quantity of fog adjustable 10-65ml/min

120, 5 minutes of continuous spray (minimum gear) more than 50 minutes of continuous spray (best fog effect)

6, water mist has the flow rate of the clean room laminar flow disturbance to the minimum 0.8-7CFM air volume can be adjusted (optional 2-25CFM)

7, human disturbance is reduced to the minimum flow needs matching wireless remote control

8, 0-60 minutes timer function

9, optional with the catheter carrier to reduce human disturbance

10, easy to use mouth (designated DI water or other ultra pure water)

11, liquid crystal screen display air volume spray time

12, automatic memory setting mode, the next measurement can be called directly



Technical parameter



The operating temperature:5℃~40℃

The voltage:AC 220V

Size:280MM*284MM*295MM

Weight :8.0KG

Tank capacity:5L

The diameter of the tube: 70MM

Droplet size: 0.3 ~ 5 μm

The spray adjustable

Flow rate: 0.8-7CFM adjustable CFM (optional 2-25CFM)

The water consumption: 10-65ml/min

The medium 2-64 megohm deionized ultrapure water smuggled goods

Wireless remote control :optional



Continuous time atomization 40-70 minutes
