ND-6330S PORTABLE PARTICLE COUNTER FOR CLEAN ROOM

Laser particle counters ND-6330S

Clean room validation instruments around you !

Laser particle counters ND-6300 series(1CFM/ 28.3L/min or 50L/min) are a kind of instrument used to measure the size and quantity of dust particles in unit volume air of clean environment, which can directly detect A and D class clean environment. With features of using diode laser light source, large touch-screen display, small size, light weight, high precision, simple operation, microprocessor control, storing & printing the measurement results and so on, this product is widely used in electronics, optical, chemical, food, cosmetics, health, biological products, aerospace, etc.

Features

User friendly interface:color touch screen operation

Stainless steel shell, no buttons, easy to clean.

Small size, light weight : portable and easy to transport

Low noise fan, with a theoretical lifespan of 20000 hours

Automatic flow regulation function 6 channels display 95% UCL calculation, automatic determination of cleanliness level Capable of printing, storing, and U disk output

Audit tracking function Optional accessories ,such as compressed air (e.g. GC101, etc.)

Optional

Compressed air GC101

Dilutor

Specification

Model ND-6330S FLow Rate 28.3L/min

Channel 0.3,0.5,1.0,3.0,5.0,10.0μm

Overall dim.(cm) 23x 18x 18cm(WxDxH)

Display 7-inch ultra large LCD display screen

Weight(approx.) 4.5kg

Standard Automatic calculation, C-GMP ,EU-GMP,GMP(2010), ISO-14644-1:2015,ISO14644-1:1999 total 7 types

Cycle 0-9999sec

Zero Count ≤10min

Printer Built-in Thermal Printer

Power Supply DC 12.6V built-in battery

Power 50W

Maximum sampling concentration 35000 P/L

Working Time 10 hours

Light source and lifetime Semiconductor laser (with a lifespan greater than 30000 hours)

Storage Sampling 8000 Report 800

Environmental condition Temperature:10℃-35℃,Humidity:20%-75%,Pressure: 86kPa-106kPa
