ND-6330S series 1CFM Portable particle counter
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Material: | Stainless Steel | Display: | 7-inchTouch Screen |
|---|---|---|---|
| Size Channels: | 0.3、0.5、1、3、5、10（μm） | Zero Count: | ≤10min |
| Printer: | Built-in Thermal Printer (stylus Printer Optional) | Date Storage: | YES |
| Working Condition: | Temperature:10~35℃; Humidity:20%~75%RH; Atmosphere Pressure: 86~106Kpa | Optional A: | Trolley For Clean Room And Compress Air Sampler ,dilutor DL-100 |
| Optional B: | Handheld Scanning Probe |
1CFM Portable particle counter
laser particle counter ND-6300(1CFM/ 28.3L/min or 50L/min) is a kind of instrument used to measure the size and quantity of dust particles in unit volume air of clean environment, which can directly detect A and D class clean environment. With features of using diode laser light source, large touch-screen display, small size, light weight, high precision, simple operation, microprocessor control, storing & printing the measurement results and so on, this product is widely used in electronics, optical, chemical, food, cosmetics, health, biological products, aerospace, etc
The laser particle counter product manufactured by Suzhou Norda Cleaning is a test instrument in Clean room. Aerosol Generator designed for air sampling.
The laser particle counter product is an essential tool for conducting clean level tests, ensuring that the cleanroom level meets the standard requirements.
In short, ND-6330F and ND6330S particle counter products are universal and efficient tools for conducting cleanliness tests. This product is capable of testing clean environments ranging from Class A to Class D, measuring particle sizes including 0.3, 0.5, 1, 3, 5, 10 μ m
, applicable to in electronics, optical, chemical, food, cosmetics, health, biological products, aerospace, etc!
Easy and simple interface,easily to operate this unit after reading operation manual one time
Support and Services:
The ND-6330F and ND6330S particle counter product offers comprehensive technical support and services to ensure optimal performance applicationand reliability. Our team of experts is available to assist with product installation, troubleshooting, and maintenance to keep your equipment running smoothly.
Packing and Shipping:
Product Name: ND-6330F and ND6330S particle counter products
Description: Our ND-6330F and ND6330S particle counter product is designed to test the cleanliness level of clean rooms.
Package Contents: The product includes the particle counter product , particle counter solution, instructions manual, and safety precautions.
Shipping: The product will be carefully packaged to ensure safe delivery. We offer standard and expedited shipping options to meet your needs.
Regular information
Weight 4.5 kg Flow rate 28.3L/min(optional)
Size channels 0.3,0.5,1,3,5,10(μm)
UCL Calculation display directly (particles/cubic meter); 95%UCL
Sample time 0-9999sec
Zero count ≤10min Printer Built-in thermal printer (stylus printer optional)
Alarm 100,1000,10000(Class) Max. Particle concentration 35000 particles/L
Operating Time 9 hours or above Light source semiconductor laser(30000 hours)
Date storage 8000 groups
Working condition Temperature:10~35℃; Humidity:20%~75%RH; Atmosphere Pressure: 86~106Kpa
