KM HEPA Leak/AG-250 Aerosol Generator (KM-Germany)

I'm Online Chat Now

KM HEPA Leak/AG-250 Aerosol Generator (KM-Germany)

China KM HEPA Leak/AG-250 Aerosol Generator (KM-Germany) supplier

Large Image :  KM HEPA Leak/AG-250 Aerosol Generator (KM-Germany)

Product Details:

Place of Origin: Germany
Brand Name: KM
Model Number: AG-250

Payment & Shipping Terms:

Minimum Order Quantity: www.nordachina.com/en
Price: www.nordachina.com/en
Packaging Details: www.nordachina.com/en
Delivery Time: www.nordachina.com/en
Payment Terms: www.nordachina.com/en
Supply Ability: www.nordachina.com/en
Contact Now
Detailed Product Description



More information: sales2@norda-china.com



Description

AG 250 aerosol generator

AG 250 aerosol generator has been designed for generating test aerosols with defined properties. The in-built flow meter with needle valve allows adjustment of the required concentration. By using the VD 100 dilution system combined with the AG 250 and a particle counter, the control of clean rooms, laminar flow boxes and safety work benches is enabled.

   Principal application fields of the AG 250 are filter tests, acceptance- and control measurements of clean rooms, laminar flow boxes and safety work benches. The compact stainless steel housing ensures very easy handling and operation. The AG 250 features a controllable flow meter for adjustment of the required concentration. Centrepiece of the AG 250 is a binary nozzle with pressurized air supply according to the injector principle and a free accessible container for the liquids to be atomized.

  • User friendly
  • Low maintenance
  • Variable concentration
  • Very high particle generation
  • Stainless steel housing

Specification

Air flow range 0.1-2500m3/h
Aerosol concentration 5.2×106pcs/cm3@250L/h
Air pump flow rate 0-500L/h
Aerosol type DEHS, PAO, DOP, Polydispersed
Generator type 1 Nozzle
Compressed air Build-in air compressor
Power supply 110-240V AC, 50/60Hz
Overall dim.(mm) 280×120×150
Weight(kg) 4
